Initialize the types of labelings on states and edges.

Label types by example

Use a dict for each label type you want to define, like this:

>>> types = [
        {'name': 'drink',
         'values': {'tea', 'coffee'},
         'setter': True,
         'default': 'tea'},
    ]

This will create a label type named 'drink' that can take the values 'tea' and 'coffee'.

Assuming this label type applies to nodes, you can now label a new node as:

>>> g = LabeledDiGraph(types)
>>> g.add_node(1, drink='coffee')

If you omit the label when adding a new node, it gets the default value:

>>> g.add_node(2)
>>> g.node[2]
{'drink': 'tea'}

The main difference with vanilla networkx is that the dict above includes type checking:

>>> type(g.node[2])
tulip.transys.mathset.TypedDict

The 'setter' key with value True creates also a field g.drink. Be careful to avoid name conflicts with existing networkx MultiDiGraph attributes.

This allows us to add more values after creating the graph:

>>> g.drink
{'coffee', 'tea'}
>>> g.drink.add('water')
{'coffee', 'tea', 'water'}

Finally, the graph will prevent us from accidentally using an untyped label name, by raising an AttributeError:

>>> g.add_node(3, day='Jan')
AttributeError: ...

To add untyped labels, do so explicitly:

>>> g.add_node(3, day='Jan', check=False)
>>> g.node[3]
{'day': 'Jan', 'drink': 'tea'}

Details on label types

Each label type is defined by a dict that must have the keys 'name' and 'values':

• 'name': with str value
• 'values' : B implements __contains__ used to check label validity.

  If you want the codomain B to be extensible even after initialization, it must implement method add.

and optionally the keys:

• 'setter': C with 3 possibilities:
  • if absent, then no setter attribute is created
  • otherwise an attribute self.A is created, pointing at:
    • the given co-domain B if C is True
    • C, otherwise.
• 'default': d is a value in B to be returned for node and edge labels not yet explicitly specified by the user.

Parameters:

• node_label_types - applies to nodes, as described above.
• edge_label_types - applies to edges, as described above.
• deterministic - if True, then edge-label-deterministic

Overrides: object.__init__

(inherited documentation)

Return states controlled by player n.

'controlled' means that player n gets to decide the successor state.

Parameters:

• n (0 or 1) - player index (id number)

Returns: set

set of states

Return the index of the player controlling edge e.

Parameters:

• e (2-tuple of nodes (n1, n2))

Returns: integer 0 or 1
